Alpine Overhead Doors Redi-Storm® IMB
Alpine Overhead Doors logo

Alpine Overhead Doors

Alpine Overhead Doors, Inc. is an innovative, quality driven US-based manufacturer of rolling doors since 1972. Our success is fueled by a passion for designing doors that are built to perform and to last. We are dedicated exclusively to the rolling door market. Our products can be found across the United States and around the world, serving a wide variety of purposes and environmental challenges. Our production facility currently manufactures over 70 different models, and growing. Alpine is a privately held, family owned company based in New York. We follow a made-to-order production process – crafting each door to the customer’s exact size, specifications and requirements. This hands-on, individual design and manufacturing approach to every job ensures customer satisfaction. Simply, we design each door as a “special project” and not as a replicated product. We source the highest quality metals, materials and components only from established, reputable suppliers – those that closely share our mission and vision.

Alpine Overhead Doors logo

Alpine Overhead Doors

Click to Call

8 Hulse Road, East Setauket, NY, 11733

Website

Download files for this product
Log in or create a free account to continue
  • Free, unlimited downloads
  • All formats: CAD, Revit, 3D, Specs
  • Manufacturer-provided, up-to-date files
Redi-Storm® IMB  preview 1
Redi-Storm® IMB  preview 1
Redi-Storm® IMB

Redi-Storm® IMB Face Mounted to Masonry

Product Features:Insulated hurricane protection device with an R-value of 8.01Approved by Dade County Florida and Florida Building Commission to withstand 187 mph windsTorsion counterbalance assemblyUnderwriters Laboratories Inc. reviewed for consumer confidenceFunctional Benefits:Insulated front slat has been missile tested to ensure safety against flying debrisDesign pressure of +60 psf & -60 psf, 1.5 Safety factor, 90+/- psfAll operating systems can be adapted to specific conditions such as; inclement weather, corrosive atmospheres, etc.Air infiltration – manufactured to meet 2015. IECC®, ASHRAE®90.1 and California’s Title 24, tested independently to meet 0.3 CFM/FTWeather seals consist of a neoprene hood baffle, vinyl guide weather stripping and vinyl astragal on the bottom bar, with an option for 1½” perimeter brush seals
Redi-Storm® IMB

Redi-Storm® IMB Face Mounted to Masonry

Product Features:Insulated hurricane protection device with an R-value of 8.01Approved by Dade County Florida and Florida Building Commission to withstand 187 mph windsTorsion counterbalance assemblyUnderwriters Laboratories Inc. reviewed for consumer confidenceFunctional Benefits:Insulated front slat has been missile tested to ensure safety against flying debrisDesign pressure of +60 psf & -60 psf, 1.5 Safety factor, 90+/- psfAll operating systems can be adapted to specific conditions such as; inclement weather, corrosive atmospheres, etc.Air infiltration – manufactured to meet 2015. IECC®, ASHRAE®90.1 and California’s Title 24, tested independently to meet 0.3 CFM/FTWeather seals consist of a neoprene hood baffle, vinyl guide weather stripping and vinyl astragal on the bottom bar, with an option for 1½” perimeter brush seals
  • About
Asset Category Filters:
  • Select All
  • PDF
Products in same Family
VIEWING Redi-Storm® IMB Face Mounted to Masonry
Redi-Storm® IMB Face Mounted to Masonry
Redi-Storm® IMB Face Mounted to Steel
Redi-Storm® IMB Face Mounted to Steel
Redi-Storm® IMB Between Tube Mounted
Redi-Storm® IMB Between Tube Mounted
