Haws Corporation Model 1920HO: Vandal-Resistant Motion-Activated Bottle Filler
Haws Corporation logo

Haws Corporation

All Haws drinking fountain and electric water cooler models are designed to be lead-free, environmentally safe and meet ADA requirements. Haws Corporation has a registered ISO 9001 Management System. Every product that leaves the Haws plant is of the highest quality and craftsmanship and is built for years of service.

Haws Corporation logo

Haws Corporation

Click to Call

1455 Kleppe Lane, Sparks, NV, 89431-6457

Website

Download files for this product
Log in or create a free account to continue
  • Free, unlimited downloads
  • All formats: CAD, Revit, 3D, Specs
  • Manufacturer-provided, up-to-date files
Model 1920HO: Vandal-Resistant Motion-Activated Bottle Filler preview 1
Model 1920HO: Vandal-Resistant Motion-Activated Bottle Filler
Model 1920HO: Vandal-Resistant Motion-Activated Bottle Filler
Model 1920HO: Vandal-Resistant Motion-Activated Bottle Filler preview 1
CAD Preview
MFG CAD Preview
Model 1920HO: Vandal-Resistant Motion-Activated Bottle Filler

Model 1920HO: Vandal-Resistant Motion-Activated Bottle Filler

Model 1920HO touchless vandal-resistant satin stainless-steel bottle filler uses a sensor operated stainless steel solenoid valve controlled by a transformer for hands-free operation. A pressure regulator is used to adjust the flow according to incoming water pressures. It can be a stand-alone station, or mounted above the Haws 1001, 1011, 1107L, 1109, 1117L and 1119 series drinking fountains.Touchless operation for safety and peace of mindVandal resistant components include the sensor casing and bottom plate100% lead-free waterwaysSatin stainless steel finishAvailable steel wall mounting plate recommended1 gpm (3.78 L) Laminar flowThis product requires a mounting plate; either the 6700 in-wall or the 6700R on-wall support plate. (See options below)Haws manufactures drinking fountains, faucets and electric water coolers to be lead-free by all known definitions including NSF/ANSI/CAN 61- Section 9, NSF/ANSI/CAN 372, California Proposition 65, and the Federal Safe Drinking Water Act. Product is compliant to California Health and Safety Code 116875 (AB 1953-2006), and 116876 (AB 100) “NSF/ANSI/CAN 61: Q ≤ 1”Prop 65 Warning. For California Residents Warning: This product contains a chemical known to the State of California to cause cancer and/or birth defects or other reproductive harm. Please click here for more information.
Model 1920HO: Vandal-Resistant Motion-Activated Bottle Filler

Model 1920HO: Vandal-Resistant Motion-Activated Bottle Filler

Model 1920HO touchless vandal-resistant satin stainless-steel bottle filler uses a sensor operated stainless steel solenoid valve controlled by a transformer for hands-free operation. A pressure regulator is used to adjust the flow according to incoming water pressures. It can be a stand-alone station, or mounted above the Haws 1001, 1011, 1107L, 1109, 1117L and 1119 series drinking fountains.Touchless operation for safety and peace of mindVandal resistant components include the sensor casing and bottom plate100% lead-free waterwaysSatin stainless steel finishAvailable steel wall mounting plate recommended1 gpm (3.78 L) Laminar flowThis product requires a mounting plate; either the 6700 in-wall or the 6700R on-wall support plate. (See options below)Haws manufactures drinking fountains, faucets and electric water coolers to be lead-free by all known definitions including NSF/ANSI/CAN 61- Section 9, NSF/ANSI/CAN 372, California Proposition 65, and the Federal Safe Drinking Water Act. Product is compliant to California Health and Safety Code 116875 (AB 1953-2006), and 116876 (AB 100) “NSF/ANSI/CAN 61: Q ≤ 1”Prop 65 Warning. For California Residents Warning: This product contains a chemical known to the State of California to cause cancer and/or birth defects or other reproductive harm. Please click here for more information.
