NanaWall® HSW60


The HSW60 is a thermally broken, aluminum framed single track sliding system, designed to provide an opening glass wall or storefront with any custom panel size within the limitation of the Maximum Size Chart. Different panel widths are possible with additional tracks in the stacking bay for the different widths. Sliding panels convertible to incorporated swing entry/exit panel(s) are possible. An end panel can be a swing panel hinged to a side jamb. Swing panels are single acting but can be either inward or outward opening. Possible configurations and stacking bay options are virtually limitless.
