NanaWall® SL82


The SL82 is a thermally broken aluminum folding panel system that presents a stunning almost uninterrupted exterior glass façade combined with weather resistance and overall superior performance. Exterior layered glass overlapping the slim surrounding aluminum profile closely achieves the highly aesthetic quality of an edge-to-edge allglass system. It is designed to provide an opening glass wall or storefront up to 39’ (12 m) wide (see Maximum Size Chart). The SL 82 is available in various configurations utilizing one to twelve panels (see elevation drawings). An option for swing entry/egress panel(s) is available. Units can only be inward opening (see details in the section drawings).
