Northern Facades

Axiom Aluminum Plate Panel System – Rainscreen


  • Solid metal plate wall system. Available 2mm pre-finished or 3mm post-painted
  • Limitless design flexibility through material choice, form and colour
  • Designed for thermal expansion and contraction without binding, rattling or misalignment
  • Ideal for curves, tapers and tight radius corners


AXIOM panels are fabricated from tension leveled, architectural grade aluminum plate, complete with shop installed stiffening ribs (if required). Panel corners are welded on 3mm panels to provide a seamless finish. On 2mm panel corners are non-welded providing a sharper return edge.

In aluminum, the 3mm lightweight panels are factory painted, in an controlled environment, after forming, which allows for limitless applications and the ultimate in design flexibility. 2mm prepainted panels are also available as well as other non-ferrous materials such as zinc and stainless steel.


AXIOM is a solid metal plate wall system uniquely designed and tested as a pressure equalized rainscreen. The Axiom System meets all of the requirements of the latest edition of the National Building Code for non-combustible construction and is considered a true dry-joint “Rainscreen Principle” system. This system should be considered when codes prevent the use of composite panel.

CAD Drawings Northern Facades Axiom Aluminum Plate Panel System – Rainscreen
