SCH Enterprises LLC

Model TR 8012 Trash Receptacle


MODEL TR 8012 TRASH RECEPTACLE

SIDEWALL OPTIONS

• Flat bar slats; flat bar slats, deviating sizes; 5/8" solid round bar; or 5/8” solid round bar and flat bar combination. Designate “-FBS”; “-FB”; "-RB", or “-RFB” for the sidewall material after the model designation.

STANDARD SIZES

• Receptacles are available in 32 or 36 gallon standard sizes (optional larger sizes are available). Designate “-32” or “-36” after the sidewall designation for a 32 or 36 gallon trash receptacle respectively.

MOUNTING OPTIONS

• Surface flange mount for bolting to existing concrete (standard); freestanding; elevated surface mounted legs; pedestal mounted (embedded or surface); or embedded (optional). Designate “-F”, “-FS”, “-EL”, “-PSE”, “-PSF”, or “-E” after the trash receptacle size for surface flanged, freestanding, elevated legs, embedded pedestal mounted, flanged pedestal mounted, or embedded mounting respectively.

FINISH OPTIONS

• Hot-dipped galvanized; polyester powder coated; thermoplastic powder coated; or stainless steel with a #4 satin finish. Designate “-G”, “-P”, “-T”, or “-SS” after the mounting option for a galvanized, powder coated, thermoplastic powder coated or stainless steel finish respectively.

TOP OPTIONS

• Flat steel top (standard); low tapered steel top (standard); low domed steel top; low domed steel top with self closing door; tapered steel top; domed steel top; or flat steel top with elevated steel canopy. Designate “-F”, “-LT”, “-LD”, “-LDD”, “-TT”, “-DT” or “-FC” after the finish option for a flat steel top, low tapered steel top, low domed steel top, low domed steel top with self closing door, tapered steel top, domed steel top, or flat steel top with elevated steel canopy respectively.

ACCESSORIES

1. Ash urn insert for domed steel top and flat steel top with elevated canopy. Designate “-AU” after top option for optional ash urn.
2. Side opening door with latch or lockable latch (City Slicker Only). Designate “-SD” or “LSD” after the top option for side opening door or lockable side opening door respectively.
3. Optional elevated legs
4. Leveling feet for surface mounted or freestanding receptacles. Designate “-LF” for leveling feet.

LINERS

• Trash receptacles come standard with either a powder coated steel liner or rigid plastic liner.
CAD Drawings SCH Enterprises LLC Model TR 8012 Trash Receptacle
CAD Drawings SCH Enterprises LLC Model TR 8012 Trash Receptacle
