Model 3500: ADA Outdoor Stainless Steel Pedestal Drinking Fountain
The Haws 3500 superior-duty stainless steel vandal-resistant pedestal drinking fountain incorporates a patented stainless steel push-button valve assembly allowing for front access stream adjustment as well as cartridge and strainer access. This pedestal mounted fountain offers the 'only' all stainless-steel valve body that is machined out of solid bar stock, is fully serviceable through the front of the push button assembly offering access to the water control cartridge and integral water supply strainer, and has front access to the water stream height adjustment for easy maintenance without having to remove the valve. Maintenance is made easy through a heavy gauge stainless steel access door with heavy-duty hinges and key lock. The "Hi-Lo" barrier-free design of the 3500 allows the square pedestal to be placed securely in multiple locations, all while providing for twice the users as regular drinking fountains. Equipped with numerous vandal-resistant components, this fountain is not easily disrupted, quickly discouraging the worst of vandals.
- Only stainless steel valve body that is machined out of solid bar stock
- Powder-coated green 12 gauge Type 304 Stainless Steel pedestal with integral 3/8" (.95 cm) thick cast stainless steel basins and welded integral mounting base plate
- Push-button operated stainless steel valves with front-accessible cartridge and flow adjustment
- Vandal resistant components include the bubbler, button, drain, and bottom/access plates
- Large access door with heavy duty hinges and square key locks
- 100% lead free waterways
Model meets all current Federal Regulations for the disabled including those in the Americans with Disabilities Act. Haws manufactures drinking fountains, faucets and electric water coolers to be lead-free by all known definitions including NSF/ANSI/CAN 61- Section 9, NSF/ANSI/CAN 372, California Proposition 65, and the Federal Safe Drinking Water Act. Product is compliant to California Health and Safety Code 116875 (AB 1953-2006), and 116876 (AB 100) "NSF/ANSI/CAN 61: Q ≤ 1".
Prop 65 Warning. For California Residents Warning: This product contains a chemical known to the State of California to cause cancer and/or birth defects or other reproductive harm. Please click here for more information.
