Steel Adjustable Net System
Create a multi-sport court with this versatile easy-to-use adjustable net system. This recreational quality post set is great for backyard courts or any facility that has limited space and wants a multi-use court such as apartment complexes, churches, home owners associations or even hotels.
With the Douglas® Adjustable Net System you simply adjust the collars anywhere from ground level to 8’ on the pole to play a variety of court sports including pickleball, tennis, badminton and volleyball.
QUICK SPECIFICATIONS
- Net System adjusts from Pickleball to Volleyball height
- 3.5″ SQ tubing with a 3/16″ wall thickness
- Black baked-on polyester powder coat finish
- Rugged, smooth operating net tensioning reel
- Removable handle for safety and convenience
- Sold per pair
- For indoor and outdoor use
- 5-Year Limited Warranty
POST
This solid system is made in the USA and is constructed of 3-1/2″ square tubing with a 3/16″ wall thickness. Poles are 12′ long and go into the ground 3’6″, leaving poles at 8’6″ above ground. All steel components are finished with a black, baked-on polyester powder coat finish. This strong finish adds resistance to chipping and the ultimate weather protection against the elements.
HARDWARE
The rugged net tensioning reel case and gears are constructed of heavy-duty steel. This simple reel assembly is easy to use and has smooth operation. The handle has a comfortable contoured grip and is removable to prevent unwanted tampering.
Includes all hardware to setup the adjustable net system including reel collar, pulley collar, and (6) eye bolt collars.
WARRANTY
5-Year Limited Warranty
