Stellar by Heat & Glo

Open Hearth: Single Sided


This dynamic design eliminates extra structural engineering and more complex installation required by masonry products and an unobstructed view of the beautiful flames.
  • CAD drawings available in 3’-8’ widths now
    -Single sided UL Certified up to 3’ height
    -Custom sizes from 9’-20’+ width
    -24” depth with ribbon burner
    -20,000 BTU’s per ft – robust flames
  • Flush hearth designs available
  • Can bring non-combustible finishing materials right up to the fireplace opening for a true clean look
  • Combustible mantel can be placed 12” above the opening
  • Flexible venting to get around structural challenges. Vented with B-vent pipe with up to 11 elbows and 100’ feet runs. Can vent downward up to 6’
  • Minimal heat output for year-round comfort
  • Customize interior with mirror or Envision panels and driftwood log set
  • Can be designed with ledge to support field installed refractory liner
CAD Drawings Stellar by Heat & Glo Open Hearth: Single Sided
CAD Drawings Stellar by Heat & Glo Open Hearth: Single Sided CAD Drawings Stellar by Heat & Glo Open Hearth: Single Sided CAD Drawings Stellar by Heat & Glo Open Hearth: Single Sided
